Name: Bang &amp; Olufsen Beosound Shape Wall-Mount Speaker
Brand: B&amp;O
SKU: 2237
Availability: InStock

Description

B&O Beosound Shape Overview

The B&O Beosound Shape is a wall-mounted speaker that is mounted on a back plate. It is equipped with an amplifier and speaker and connects via one cable to a control box and power socket. The speakers can be hidden in the wall. This is a great feature for homes with limited wall space.

B&O Beosound Shape Feature

The Beosound Shape is also aesthetically pleasing. Its hexagonal shape is customizable, and you can select from ten different colors for the covering. It also features a smart tool to help you position it where it will provide the best sound. The installation process is easy and does not require a team of audio engineers.

Designed to fit any room, the BeoSound Shape is a modular wall-mounted wireless speaker system. You can combine the modules to suit your needs and design. The BeoSound Shape features a removable grille, amplifier, smart hub, speaker, and acoustic dampers. You can even choose different patterns or colors for the speaker modules.

B&O Beosound Shape Specification

Weight	2.0 kg + 0.4 kg (fabric cover)
Power amplifiers	8 x 80 Watt (Class D)
Maximum Speakers per Amplifier	4
Cabinet Color	Black
Connections	AC power (note if multiple amplifiers, each requires its own AC power connection) Optical digital audio input USB (for control and SW update) Powerlink input Amplifier input (sound & control input), for daisy chaining of amplifiers Amplifier output (sound & control output), for daisy chaining of amplifiers 4 x speaker 4-wire output

SPEAKER TILE

Weight	1.9 kg + 0.4 kg (fabric cover)
Cabinet principle	Closed box
Cabinet Color	Black
Connections	1 x speaker 4-wire input
Speaker Drivers	Woofer 5¼” Tweeter ¾”

ACOUSTIC DAMPER TILE

Weight	0.51 kg + 0.4 kg (fabric cover)
Cabinet Color	Black

TECHNICAL

Maximum Sound Pressure Level @1m	105 dB (8 tiles setup)
Bass capability @1m	89 dB (8 tiles setup
Frequency Range	30 – 22.000 Hz (8 tiles set up)
Features	Band on the wall Thermal Protection Adaptive Bass Linearization
Remote Control	Bang & Olufsen App Beoremote Halo Beoremote One Beosound Core can be paired wirelessly (Bluetooth Low Energy) with the Beoremote Halo or Beoremote One to complete the music listening experience.

CONNECTIVITY P R O V I D E D B Y BEOSOUND CORE

Beosound Core Dimensions and Weigh	Base diameter: 151.2 mm Height: 43.5 mm Weight: 290 g USB-C power supply weight: 150 g
Supported Audio Formats	MP3, WMA, AAC, ALAC, FLAC, WAV, AIFF Standard sample rates up to 192 kHz, stereo andup to 24 bit Note: WMA lossless is not supported
Streaming technologies	Chromecast built-in Apple AirPlay Bluetooth Audio Streaming DLNA – DMR Spotify Connect QPlay 2.0 (China specific) Embedded music services Deezer & TuneIn (Internet Radio)
Wireless Networks	Wi-Fi/WLAN 802.11 a/b/g/n/ac (2.4 GHz & 5 GHz) and Bluetooth 4.1
Connectors	1 x USB-C (for power via external power supply) 1 x Powerlink socket (RJ45) with two channels 1 x Line-in (analogue & digital combo) with sensing 1 x Ethernet 1 x Optical digital sound out (for connection to · the BeoSound Shape) 1 x USB (for connection to the BeoSound Shape) 1 x Connector for IR-eye

BASIC

Product Dimensions ( W x H x D )	36.4 x 32 x 11.1 cm
Weight	15 kg (8 tiles setup)
Placement	Wall
Recommended Room Size	20-100 m² / 200-1000 ft²
System Dimensions	Tile with fabric and star rail mounting system: 36.4 x 32.0 x 11.1 The star rail system makes a 6 mm air gap between cabinet and wall
Systems Maximums	Maximum amplifier tiles: 11 Maximum speaker tiles: 44 Acoustic damper tiles: unlimited

Explore more from our collection.

Additional information

Color	Grey Define, Dark Grey, Dark Oak, Warm taupe, Black, Purple Heart, Brown, Pink, Brazilian Clay, Parisian Night Blue, Wild Drove Grey, Moss Green, Dark Blue
