Description
The Alltrax is an advanced controller for DC Series motor projects.
Works with all of our brushed motors like the ME0909 , ME0708 ME0709 and ME1003, 1004.
* 12-48v Nominal Models 48300, 48400, 48500, 48600 now in stock! Please contact us if interested in the Alltrax 48400, 48500 or 48600.
*User Personality Switch Input
*USB Programming with Free Software
*Contactor Control for main DC power
*Optional Fan Panel (standard on 500 and 600 amp models)
*Water, Vibration and Corrosion resistant
Technical Specifications
| Specifications | Units | Alltrax SR 48300 |
| Voltage | Volts | 12-48V Nominal, 62V Max |
| Peak Amps | Amps | 300 (350 Peak Amp Mode Enabled in Alltrax Toolkit program) |
| Continuous Amps | Amps | 210 |
| Operating Frequency | kHz | 18 |
| Standby Power | W | <1W, <8W with fan on |
| Relay Drive Current | Amps | 5 peak, 1 Continuous |
| Terminal Torque | Nm | 6.77 – 9.4 |
| Operating Temperature | deg F | 68 – 167 |
| Weight | lbs | 3.3 |
| Dimensions | L x W x H (inches) | 9 x 5.5 x 3.5 |
| Dimensions | L x W x H (mm) | 228 x 140 x 89 |
| Throttles supported | 0-5k, 5k-0, E-Z-GO ITS, Club Cart 5k-0 3 Wire (MCOR), 0-5v, Taylor Dunn 6v-10.5v, USB Throttle, Yamaha 0-1k, Absoute Mode |
